RJ45 Application Solution (10/100/1000)

Dongchen's Ethernet protection arrays provide low clamping voltage and low capacitance. Ethernet is everywhere, from telecommunications backhaul to computing connectivity to industrial networking. Ethernet has become a dominant communication standard in the electronics industry. Ethernet ports are exposed to external transient events in the form of ESD, EFT, lightning, and cable discharge events (CDE). State-of-the-art protection is needed to adequately safeguard these interfaces from the many overvoltage threats and Dongchen offers ideal solutions.



Features
  • lProtects up to eight lines
  • lProtect high-speed data and transmission lines
  • lVery low capacitance
  • lLow clamping voltage
  • lFlow-through trace routing
  • lHigh surge capability




Applications
  • l10/100/1000 Ethernet interfaces
  • lNotebooks, desktops, and servers
  • lCentral office equipment
  • lVideo surveillance systems
  • lGPON systems
  • lVoIP phones
  • lAutomotive

Using a four-channel TVS Array component to complete line-to-ground ESD protection. The recommended part number is DCENX3V340LSCT, and its package is DFN3020. When routing PCB, you can use the straight-pull method, which is quite convenient. The parasitic capacitance of DCENX3V340LSCT I/O to ground is 1.7pF (Typ.), and the ESD protection capability can reach ±30kV in contact mode and ±30kV in air mode.
